iBASE SE-102-N Dual Output, -40°C to +70°C, Digital Signage Player

£708.00£1,012.32 inc.Vat | £590.00 ex.VAT

Dual output, extreme temperature digital signage media player with on / off scheduling functionality via BIOS. Available in 4GB or 8GB RAM options and expansion slots for Wifi & Bluetooth or 4G.

Clear

Product Description

Great for Outdoor Projects


Eclipse Digital Media - Digital Signage AV Shop - iBASE SE-102-N - Designed for Outdoor Projects

This unit has been designed with outdoor use in mind. Although not suitable for directly mounting without weather protection, the unit has been tested to pass extended operating temperatures (-40°C to +70°C*) and meet extreme system reliability requirements that allow its deployment in a wide range of outdoor environments. The super slim (19.5mm), fanless / noiseless design also has a Mini PCI-E slot for optional WiFi, Bluetooth or 4G connectivity.

*does not include power supply unit (PSU)

Reliable, Stable & Efficient


The system comes with a lower-power Intel® Atom™ x7 / E3950 (1.6~2.0GHz) quad-core processor and Intel® HD Graphics. These combine both excellent performance and efficiency to ensure commercial-grade reliability and stable operation. It also offers two dual-channel DDR3 RAM sockets to provide up to 8GB memory along with a 64GB mSATA SSD for low heat emission and faster system boot up.

Eclipse Digital Media - Digital Signage AV Shop - iBASE SE-102-N - Intel Atom Processor

Dual HDMI Output with built-in EDID


Eclipse Digital Media - Digital Signage AV Shop - iBASE SE-102-N - Dual Output HDMI EDID


The SE-102-N has dual HDMI 1.4b output allowing the connection of two monitors. The outputs also include hardware EDID emulation meaning if one screen goes down / output is removed, the other output remains unaltered. This avoids any unwanted squashing / convergence of content being displayed.

iSMART Technology


iSMART is a unique technology that iBASE created for protecting and enabling systems. iSMART provides various options via the BIOS such as automatic power on/off scheduling (shutdown and autostart OS), power failure detection and temperature monitoring to reduce downtime and save power.

Eclipse Digital Media - Digital Signage AV Shop - iBASE iSMART Technology

Optional Digital Signage Software


eclipse digital media embed signage certified reseller

Use this device with embed signage to maximise the features of the unit for Digital Signage running Windows OS.

Features include:

  • Multi-output support, perfect for video walls
  • Live streams via YouTube and IPTV supported
  • Customise position and dimension of content playback, ideal for LED walls
  • Run software in Kiosk mode to ‘lock down’ device
  • RS232 support for triggering content
  • and a whole lot more [opens external link]

Download PDF


iBASE SE-102-N Datasheet PDF

Buying bulk?


For the best prices give us a call on: +44 (0)8450 944 954

Additional Information

Weight 3 kg
Dimensions 290 x 230 x 100 mm
Dimensions

190mm(W) x 130mm(D) x 19.5mm(H)

I/O Interface

2x HDMI 1.4b with hardware EDID emulation
3x USB 3.0 port
1x RJ45 for Gigabit LAN
1x RJ45 for RS232 serial port
2x audio connectors for Line-in / Line-out
Power / HDD LED, 1x power on/off button
1x DC jack

Operating Temperature

-40°C~70°C (-40°F~158°F)

Relative Humidity

5%~90% @45oC (non-condensing)

Certification

CE, FCC class B, cULus & CCC
